Elimination of blade tip vortices of aircraft propellers

  • Peter from Laser Consult Ltd.
  • From Hungary
  • Responsive
  • Innovative Products and Technologies

Summary of the technology

TECHNOLOGY/PRODUCT OVERVIEW

Blade tip vortex is a powerful phenomenon that develops very quickly. However, ‘widening’ the blade tips increases the possibility of greater power and performance, at the same time, the vortex losses generated at the blade tips increase drastically. The solution currently used to reduce the vortices of the blade tips is reducing the angle of attack close to the blade tip. This is how it tries to avoid significant losses. At the same time, naturally, the drag force or the transmittable power decreases.
Eliminating or reducing blade tip losses (eliminating vortices around the blade tip) means significant fuel savings and increased lifespan, efficiency, and performance especially when using wide blade tips.
The elimination of blade tip loss reduces vibrations, thus reducing internal friction of the structure’s material, thereby increasing lifespan. This results in significant financial savings, e.g. in the case of a modern blade.
Due to centrifugal force, the “winglet” used on wings moving in a linear direction cannot be used in the case of a rotating system.

Laser Consult Ltd.
Laser Consult Ltd.
Laser Consult Ltd.

Details of the Technology Offer

Elimination of blade tip vortices of aircraft propellers

The blade tip vortex is a powerful phenomenon that develops very quickly. Especially for wide-end propellers a significant amount of blade tip vortices is generated.

The consequences of blade tip vortex include noise, structural vibrations, and reduced efficiency and performance. The detached vortex can damage the blade tip, which in turn decreases the lifespan of the blades, necessitating more frequent replacements

The technical solution provides an approach to eliminate blade tip losses. The elimination of turbulence causing energy loss on the blade tips means greater drag force, torque, and efficiency. Vortex interference is used to eliminate vortices and turbulence that cause losses at the blade tips.

The structural solution has resulted in an 8-13% increase in air time, thereby improving range and fuel efficiency, depending on flight conditions. These findings are supported by a recent patent search report.

TECHNOLOGY/PRODUCT FEATURES, TECHNICAL DATA AND BENEFITS

These newly developed propellers eliminate harmful turbulence at the tip of the propeller blade. The resulting benefits provide many possibilities for keeping and moving aircrafts and drones in the air:

For airplanes:

  • fuel can be saved,
  • range can be greater,
  • time spent in the air can be more,
  • vibration generated by the propeller can be reduced,
  • lifespan of the propeller can be increased,
  • number of propeller blades can be reduced.

For drones, due to the favorable features of the propellers:

  • range can be greater,
  • operation can be quieter,
  • there can be more favorable flight characteristics,
  • energy consumption can be reduced,
  • own weight/liftable payload ratio can increase positively.

The innovative solution opens up many new possibilities in structural and industrial design. Extreme shapes may be created more easily. There are more possibilities regarding the number, location and operation of engines, movement, and hovering. Drones may fly for several hours or can have a greater range.

Helicopters:

  • thanks to the new design, the rotor can be more efficient and quieter,
  • it can be particularly beneficial for smaller vehicles: calmer and more silent operation and speed,
  • efficiency, range, and cost-effectiveness can also increase in the case of large, cargo vehicles.

POTENTIAL APPLICATIONS

For airscrews:

  • Airplanes
  • Drones
  • Helicopters

TECHNOLOGY/PRODUCT READINESS LEVEL

TRL 7

The technology was tested on an airplane in flight.

Comparative measurements were performed.

BUSINESS MODEL

The main target is licensing (license fee + royalty)

Joint R&D

Related Keywords

  • Helicopter
  • Energy Technology
  • Energy efficiency
  • Sustainability
  • airplane
  • drone
  • flight
